Parts scheme
List of spare parts
| Pos. | Part No | Qty | Parts name | Remark |
|---|---|---|---|---|
| *. | K9001903 | [1] | SEAL KIT;SWING MOTOR | |
| *. | K9008336 | [1] | SEAL KIT;SWING MOTOR | K9008336A |
| *. | K9008336A | [1] | ||
| -. | 170303-00050 | [2] | 170303-00050A | |
| -. | 170303-00050A | [2] | 170303-00050B | |
| -. | 170303-00050B | [2] | ||
| -. | K1000777A | [2] | MOTOR;SWING | 170303-00050 |
| 101. | K9001944 | [1] | VALVE;CASING | |
| 102. | 2.121-00009 | [2] | PLUG | |
| 103. | K9001840 | [2] | SPRING | |
| 104. | K9001841 | [2] | PLUNGER | |
| 105. | 410116-00410 | [1] | ||
| 105. | 410116-00311 | [1] | VALVE;SWING REACTIONLESS | |
| 105. | 1.420-00016 | [1] | VALVE;SWING REACTIONLESS | |
| 105. | K9006899 | [1] | VALVE;SWING REACTIONLESS | 410116-00410 |
| 106. | S8000341 | [2] | O-RING | |
| 107. | K9008333A | [2] | VALVE,RELIEF | |
| 107. | K9002674 | [2] | VALVE;RELIEF | K9008333A |
| 108. | S6005050 | [1] | BEARING;BALL | |
| 109. | S2227561 | [4] | BOLT;SOCKET | |
| 110. | 2181-1950D1 | [2] | PLUG | |
| 111. | S8000111 | [2] | O-RING | |
| 112. | K9001842 | [1] | O-RING | |
| 113. | S5741162 | [2] | PIN;SPRING | |
| 201. | K9001843 | [1] | SHAFT;DRIVE | |
| 202. | K9001844C | [1] | ||
| 202. | K9001844 | [1] | PLATE;SWASH | K9001844C |
| 203. | K9001845 | [1] | PISTON & SHOE ASS'Y | |
| 205. | 150102-00439 | [1] | ||
| 205. | K9001846 | [1] | BLOCK;CYLINDER | |
| 206. | 1.148-00015 | [1] | BALL;THRUST | |
| 207. | 110943-00057 | [1] | ||
| 207. | 1.412-00092 | [1] | PLATE;RETAINER | 110943-00057 |
| 208. | 1.114-00009 | [1] | COLLAR | |
| 209. | 1.109-00134 | [5] | ROLLER | |
| 210. | 1.114-00286 | [2] | WASHER | |
| 211. | 1.131-00048 | [1] | SPRING | |
| 212. | S6510620 | [1] | RING;SNAP | |
| 213. | 250201-01934 | [1] | ||
| 213. | K9001847 | [1] | PLATE;TIMING | |
| 301. | K9001848B | [1] | ||
| 301. | K9001848 | [1] | CASING | |
| 301. | K9001848A | [1] | CASING | K9001848B |
| 302. | 401106-00181 | [1] | ||
| 302. | 180-00219 | [1] | SEAL;OIL | |
| 302. | K9006399 | [1] | SEAL;OIL | 401106-00181 |
| 303. | S6005090 | [1] | BEARING;BALL | |
| 304. | 1.123-00053 | [1] | PIN,PARALLEL | |
| 305. | 352-00014 | [3] | PLATE,SEPARATION | |
| 306. | 412-00013 | [2] | PLATE,FRICTION | |
| 307. | 180-00220 | [2] | O-RING | |
| 308. | 180-00221 | [1] | O-RING | |
| 309. | 452-00020 | [1] | PISTON;BRAKE | |
| 310. | 129-00062 | [18] | SPRING;BRAKE | |
| 311. | 181-00346 | [1] | PLUG | |
| 311. | 2181-1116D4 | [1] | PLUG | |
| 312. | 2181-1116D2 | [1] | PLUG | |
| 313. | 2181-1950D1 | [1] | PLUG | |
| 314. | S8000111 | [1] | O-RING | |
| 400. | 410102-00024 | [1] | ||
| 400. | 420-00110 | [1] | VALVE;BRAKE | |
| 400. | 410102-00039 | [1] |
Product Description
| Appliion | Doosan Excavator |
| Quality | High Guarantee |
| Model | D520LC |
| Package | Standard Packing at Normal |
| Warranty | 1 Year |
| Payment term | T/T,, PayPal, Alibaba Trade Assurance |
| Delivery | 5 days after the payment received |
| Shipment | by sea, by air, by express or as requi |
