| Attribute | Value |
|---|---|
| Model | HMGF36 ZX200 ZX200-6 |
| Part number | 9168003 9195451 |
| Part name | Hitachi Travel Motor |
| Application | Excavator |
| Power Source | Hydraulic |
| After Warranty Service | Online Support |
| Color | According to customer requirement |
| # | Part No | Part Name | Qty. | Price request |
|---|---|---|---|---|
| 9168003 | MOTOR; OIL (FOR ASSEMBLY OF MACHINE) | 1 | ||
| 9195451 | MOTOR; OIL (FOR TRANSPORTATION) | 1 | ||
| 00 | 1025878 | . HOUSING | 1 | |
| 02 | 4396696 | . SEAL; OIL | 1 | |
| 03 | 4417431 | . PISTON | 2 | |
| 06 | 4409640 | . PIN; KNOCK | 1 | |
| 07 | 2042080 | . SHAFT | 1 | |
| 08 | 991345 | . RING; RETAINING | 2 | |
| 09 | 9173285 | . PLATE ASS'Y | 1 | |
| 09A | .. PLATE | 1 | ||
| 09B | .. PIN | 2 | ||
| 10 | 4396755 | . BRG.; ROL. | 1 | |
| 12 | 3085485 | . PLATE; SWASH | 1 | |
| 12 | 3088017 | . PLATE; SWASH | 1 | |
| 15 | 8075190 | . PISTON ASS'Y | 9 | |
| 15 | 8099321 | . PISTON | 9 | |
| 16 | 3081570 | . RETAINER | 1 | |
| 17 | 4397757 | . BUSHING | 1 | |
| 19 | 4396747 | . SPRING; COMPRES. | 6 | |
| 20 | 2042060 | . ROTOR | 1 | |
| 20 | 2052977 | . ROTOR | 1 | |
| 20 | 2051451 | . ROTOR | 1 | |
| 22 | 3081593 | . PLATE; FRICTION | 4 | |
| 23 | 3081592 | . PLATE | 4 | |
| 25 | 3081595 | . PISTON | 1 | |
| 26 | 4396775 | . O-RING | 1 | |
| 28 | 4396774 | . O-RING | 1 | |
| 29 | 3081594 | . SPRING; DISC | 1 | |
| 30 | 4420958 | . O-RING | 1 | |
| 31 | 4506415 | . O-RING | 3 | |
| 34 | 9167777 | . VALVE; BRAKE (FOR ASSEMBLY OF MACHINE) | 1 | |
| 34 | 9195450 | . VALVE; BRAKE (FOR TRANSPORTATION) | 1 | |
| 34 | 9244289 | . VALVE; BRAKE (FOR ASSEMBLY OF MACHINE) | 1 | |
| 34 | 9260017 | . VALVE; BRAKE (FOR TRANSPORTATION) | 1 | |
| 35 | 4396759 | . BRG.; NEEDLE | 1 | |
| 35 | 4631910 | . BRG.; NEEDLE | 1 | |
| 36 | 4422627 | . PIN; KNOCK (FOR ASSEMBLY OF MACHINE) | 2 | |
| 36 | 4422627 | . PIN; KNOCK (FOR TRANSPORTATION) | 2 | |
| 36 | 4610452 | . PIN; KNOCK (FOR ASSEMBLY OF MACHINE) | 2 |
