| Part Name | Hydraulic Pump |
|---|---|
| Product | Volvo Hydraulic Pump |
| Model | JS130W |
| Pump Number | PSV2-55T |
| Color | According to customer requirement |
| Warranty | 1 Year |
| Quality | Made In China |
| # | Part No | Part Name | Qty. | Price request |
|---|---|---|---|---|
| 13-16A | LBB0122 | Ring, back-up | 2 | |
| 53 | LJP0027 | Shaft, front | 1 | |
| 34-3 | N.S.P. | None serviced part | 1 | |
| 13-7 | LZP0109 | Cover, pilot, pump | 1 | |
| 24 | LBB0253 | Ring, back-up | 2 | |
| 56 | LMP0161 | Spacer | 2 | |
| 31 | 6004/3203 | Capscrew | 4 | |
| A | KNJ1025 | Pump, hydraulic | 1 | |
| 43 | LZP0110 | Body, port | 1 | |
| 46 | LMP0180 | Collar | 2 | |
| 47 | LBQ1251 | O Ring | 2 | |
| 62 | LZP0102 | Casing, oil, seal | 1 | |
| 34 | LNP0089 | Cylinder, assembly | 1 | |
| 35 | LZP0104 | Casing | 1 | |
| 58 | 370A0350Z | Ring, snap | 2 | |
| 36-2 | N.S.P. | None serviced part | 9 | |
| 13-11 | 6004/3311 | Capscrew | 4 | |
| 13-6 | LBQ0701 | O Ring | 1 | |
| 15 | LZP0108 | Cover, regulater | 2 | |
| 50 | LBQ0182 | O Ring | 3 | |
| 18 | LUP0069 | Nut | 4 | |
| 51 | KRP0401 | Plug | 3 | |
| 7 | 6004/3308 | Capscrew | 8 | |
| 64 | LZP0112 | Flange, mounting | 1 | |
| 13-12 | LDP0033 | Shaft, gear | 1 | |
| 5 | LBB0152 | Ring, back-up | 2 | |
| 52-2 | N.S.P. | None serviced part | 1 | |
| 10 | LLP0079 | Plug | 2 | |
| 14 | 1391/3409Z | Capscrew, M10 x 35mm | 4 | |
| 26 | LUP0068 | Capscrew | 8 | |
| 6 | LBQ0152 | O Ring | 2 | |
| 34-2 | N.S.P. | None serviced part | 1 | |
| 20 | LBQ0082 | O Ring | 1 | |
| 13-10 | LKP0024 | Bush | 1 | |
| 13-9C | N.S.P. | None serviced part | 1 | |
| 33 | LZP0103 | Casing | 1 | |
| 42 | LTP0035 | Bearing, inner race | 2 | |
| 27 | LPP0049 | Piston, regulater | 2 | |
| 13-3 | LLP0082 | Plug | 1 | |
| 39 | LMP0164 | Pin | 4 | |
| 63 | 6004/3709 | Capscrew | 4 | |
| 2 | LTP0032 | Bearing, roller | 4 | |
| 52-1 | N.S.P. | None serviced part | 1 | |
| 28 | LUP0087 | Screw | 8 | |
| 11 | N.S.P. | None serviced part | 10 | |
| 9 | LBQ0112 | O Ring | 2 | |
| 36 | N.S.P. | None serviced part | 1 | |
| 22 | LMP0156 | Pin | 2 | |
| 8 | LBQ0253 | O Ring | 4 | |
| 29 | LDP0036 | Plate, gear pivot | 4 | |
| 30 | LKP0026 | Bush, slide | 2 | |
| 4 | LSP0082 | Seat, spring | 2 | |
| 13-2 | LBQ0082 | O Ring | 1 | |
| 55 | LTP0034 | Bearing, roller | 2 | |
| 38 | 6004/3405 | Capscrew | 4 | |
| 13-5 | LMP0156 | Pin | 2 | |
| 12 | KXJ0106 | Capscrew | 8 | |
| 13 | LNP0099 | Pump, pilot | 1 | |
| 13-9 | LNP0136 | Casing, pilot, pump | 1 | |
| 32 | LMP0162 | Stay | 2 | |
| 17 | LUP0072 | Screw | 4 | |
| 34-1 | N.S.P. | None serviced part | 9 | |
| 44 | LCP0027 | Coupling | 1 | |
| 48 | LSP0083 | Seat, spring | 2 | |
| 36-1 | N.S.P. | None serviced part | 1 | |
| 40 | LJP0028 | Shaft, rear | 1 | |
| 13-17 | N.S.P. | None serviced part | 1 | |
| 13-9A | N.S.P. | None serviced part | 1 | |
| 1 | LDP0035 | Guide, gear assembly | 4 | |
| 13-16B | LBQ0120 | O Ring | 1 | |
| 13-14 | LKP0025 | Bush | 2 | |
| 54 | LBU0005 | O Ring | 2 | |
| 25 | LMP0160 | Stop | 2 | |
| 13-9B | LDP0031 | Gear, drive | 1 | |
| 57 | LBQ0701 | O Ring | 1 | |
| 45 | LTP0033 | Bearing, needle | 2 | |
| 13-16C | LBQ0182 | O Ring | 1 | |
| 19 | LZP0111 | Plate, swash, pump | 2 | |
| 13-18 | LBQ0092 | O Ring | 3 | |
| 61 | LAP0019 | Seal, oil | 1 | |
| 21 | LLP0082 | Plug | 1 | |
| 16 | 6004/3305 | Capscrew | 8 | |
| 52 | LNP0088 | Retainer, holder, assembly | 1 | |
| 13-16 | LNP0086 | Valve, relief | 1 | |
| 60 | LMP0165 | Ring, snap | 1 | |
| 41 | LBQ0092 | O Ring | 7 | |
| 23 | LMP0157 | Pin | 10 | |
| 13-8 | LBP0050 | O Ring | 1 | |
| 59 | LZP0105 | Flange | 1 | |
| 14 | 6004/3409 | Capscrew | 4 | |
| 36 | LNP0090 | Cylinder, assembly | 1 | |
| 37 | LZP0121 | Cover, rear | 1 | |
| 49 | LSP0081 | Kit-spring | 2 | |
| 3 | LZP0120 | Cap | 2 |
The Excavator Hydraulic Pump product technical support and services include:
Our team of experts is dedicated to providing the highest quality technical support and services to ensure optimal performance and longevity of your Excavator Hydraulic Pump.
