EX300-5 EX330LC-5 EX350H-5 EX370 hydraulic pump Belparts excavator main pump for hitachi 9166355 9169055 9166356 9169054
Quick Detail of Excavator Hydraulic Pump
Product Name:Excavator Hydraulic Pump
Brand:Belparts
Machine model:EX300-5 EX330LC-5 EX350H-5 EX370-5
Packing Size:84*38*49
Part number:9166355 9169055 9166356 9169054
Pressure:Standard, High Pressure
| Product Name | Excavator Hydraulic Pump |
| Brand | Belparts |
| Machine model | EX300-5 EX330LC-5 EX350H-5 EX370-5 |
| Packing Size | 84*38*49 |
| Part number | 9166355 9169055 9166356 9169054 |
| Pressure | Standard, High Pressure |
| # | Part No | Part Name | Qty. | Price request |
| 9166355 | PUMP DEVICE | 1 | ||
| (9169055) | PUMP DEVICE | |||
| 03 | 1019384 | . CASING; GEAR | ||
| 03 | 1026550 | . CASING; GEAR | 1 | |
| 04 | 3035852 | . GEAR; CENTER | ||
| 05 | 3081085 | . SHAFT; CENTER | ||
| 08 | 4395453 | . BRG.; BALL | ||
| 09 | 4395457 | . BRG.; BALL | ||
| 10 | 4191219 | . RING; RETAINING | 1 | |
| 11 | 4179833 | . SEAL; OIL | 1 | |
| 12 | 3033593 | . COVER; T.MISSION | 1 | |
| 13 | 4179834 | . O-RING | 1 | |
| 14 | 991733 | . RING; RETAINING | 1 | |
| 17 | 4181700 | . PUMP; GEAR | 1 | |
| 18 | M341030 | . BOLT; SOCKET | ||
| 20 | 984054 | . WASHER; SPRING | 2 | |
| 22 | 4114402 | . WASHER | 2 | |
| 23 | 4191974 | . ADAPTER | 1 | |
| 23A | 4506418 | .. O-RING | 1 | |
| 28 | 3035853 | . GEAR; DRIVE | 2 | |
| 29 | 991345 | . RING; RETAINING | 2 | |
| 32 | 9166356 | . PUMP; UNIT | 2 | |
| (9169054) | PUMP DEVICE | |||
| 35 | J901645 | . BOLT | ||
| 36 | 4126090 | . WASHER; SEAL | ||
| 37 | A590916 | . WASHER; SPRING | ||
| 40 | 4234782 | . PLUG | 1 | |
| 41 | 94-0649 | . ELBOW | ||
| 50 | 4192946 | . PIPE | 2 | |
| 52 | 4192947 | . PIPE | 1 | |
| 53 | 4179837 | . FITTING; PIPE | ||
| 53 | 4293950 | . ELBOW; S | ||
| 53A | 957366 | .. O-RING | 1 | |
| 54 | 4203485 | . FITTING; PIPE | 1 | |
| 54A | 957366 | .. O-RING | 1 | |
| 55 | 3036249 | . PIPE | 1 | |
| 56 | 3036486 | . PIPE | 1 | |
| 57 | 4118499 | . FITTING; PIPE | 4 | |
| 57A | 957366 | .. O-RING | 1 | |
| 59 | 4179843 | . CLAMP | 2 | |
| 60 | J900828 | . BOLT | 1 | |
| 61 | M500807 | . NUT | 1 | |
| 62 | A590908 | . WASHER; SPRING | 1 | |
| 63 | 4242263 | . GAUGE; LEVEL | 1 | |
| 64 | 4242262 | . PIPE | 1 | |
| 65 | M340816 | . BOLT; SOCKET | 2 | |
| 66 | 9742779 | . PACKING | 1 | |
| 67 | 3081037 | . NAME-PLATE | 1 | |
| 68 | M492564 | . SCREW; DRIVE | 2 | |
| 69 | 4265372 | . SENSOR; REVOL. | 1 | |
| 70 | 4306888 | . O-RING | 1 | |
| 71 | A590106 | . WASHER; PLANE | 1 | |
| 72 | M340616 | . BOLT; SOCKET | 1 | |
| 73 | 4191663 | . COUPLING | 1 | |
| 73A | 4216945 | .. HUB | 1 | |
| 73B | 4183170 | .. SCREW; SET | 2 | |
| 73C | 4101345 | .. PIN; SPRING | 12 | |
| 73D | 4216947 | .. INSERT | 4 | |
| 73E | 4216949 | .. BOLT; SOCKET | 4 | |
| 73F | 4216946 | .. INSERT | 4 | |
| 73G | 4216948 | .. BOLT; SOCKET | 4 | |
| 73H | 4216944 | .. COUPLING | 1 | |
| 76 | 4252767 | . BRACKET | 1 | |
| 77 | M340613 | . BOLT; SOCKET | 1 | |
| 78 | 4169516 | . WASHER; SPRING | 1 | |
| 81 | 9134111 | . PLUG | 1 | |
| 81A | 4509180 | .. O-RING | 1 |
FAQ
1.How can I be sure the part will fit my excavator ?
Give us correct model number /machine serial number /any numbers on the parts itself . We mainly sell standard and original motor.
2.What are your After-sales service?
Before shipment, Each individual product will be strictly inspected on our factory. In addition. We have a customer Service team to respond to customers' questions within 12 hours. Being helpful in solving customers' problem is always our goal.
3.How long can an order delivery?
If the order less than 10pcs, we will shipping the goods within 7days, more than 10pcs, we will shipping the goods within 15days. Arrival date depends on shipping company.
