Parts scheme
List of spare parts
| Pos. | Part No | Qty | Parts name | Note |
|---|---|---|---|---|
| 9184686 | [1] | PUMP;PISTON | ||
| 001. | 4469526 | [2] | REGULATOR | |
| 011. | 0820401 | [2] | PISTON ASS'Y | |
| 011A. | +++++++ | [9] | PISTON | |
| 011B. | +++++++ | [9] | SHOE | |
| 013. | 0820402 | [1] | CYL. ASS'Y | |
| 013A. | +++++++ | [1] | BLOCK;CYL. | |
| 013B. | +++++++ | [1] | PLATE;VALVE | |
| 014. | 0451003 | [1] | CYL. ASS'Y | |
| 014A. | +++++++ | [1] | BLOCK;CYL. | |
| 014B. | +++++++ | [1] | PLATE;VLAVE | |
| 030. | 0820403 | [1] | PLATE ASS'Y | |
| 030A. | +++++++ | [1] | PLATE | |
| 030B. | +++++++ | [1] | BUSHING | |
| 030C. | +++++++ | [1] | LEVER | |
| 030D. | +++++++ | [1] | BOLT | |
| 030E. | +++++++ | [1] | PIN | |
| 030F. | +++++++ | [1] | PIN | |
| 031. | 0820404 | [1] | PLATE ASS'Y | |
| 031A. | +++++++ | [1] | PLATE | |
| 031B. | +++++++ | [1] | BUSHING | |
| 031C. | +++++++ | [1] | LEVER | |
| 031D. | +++++++ | [1] | BOLT | |
| 031E. | +++++++ | [1] | PIN | |
| 031F. | +++++++ | [1] | PIN | |
| 111. | 0820405 | [1] | SHAFT | |
| 113. | 0820406 | [1] | SHAFT | |
| 122. | 0820453 | [1] | BRG.;ROL. | |
| 123. | 0820407 | [1] | BRG.;ROL. | |
| 124. | 0820408 | [2] | BRG.;NEEDLE | |
| 126. | 0820409 | [2] | SPACER | |
| 127. | 0820410 | [1] | SPACER | |
| 128. | 0820411 | [3] | SPACER | |
| 129. | 0820412 | [1] | SPACER | |
| 130. | 0820413 | [1] | BOOSTER | |
| 131. | 0820414 | [1] | COVER | |
| 153. | 0820415 | [2] | RETAINER | |
| 156. | 0820416 | [2] | BUSHING | |
| 157. | 0451016 | [18] | SPRING | |
| 171. | 0820445 | [1] | CASING | |
| 191. | 0820418 | [1] | GEAR;DRIVE | |
| 192. | 0820419 | [1] | GEAR | |
| 211. | 0451018 | [2] | PLATE | |
| 251. | 0820420 | [2] | SUPPORT | |
| 261. | 0820440 | [1] | COVER;SEAL | |
| 262. | 0820422 | [1] | COVER | |
| 271. | 0820454 | [1] | CASING | |
| 312. | 0820447 | [1] | COVER;VALVE | |
| 402. | 0237902 | [4] | BOLT;SOCKET | |
| 405. | 0820448 | [8] | BOLT;SOCKET | |
| 406. | M341236 | [8] | BOLT;SOCKET | |
| 408. | 0131103 | [11] | BOLT;SOCKET | |
| 409. | 0820425 | [2] | BOLT;SOCKET | |
| 410. | 0820426 | [9] | BOLT;SOCKET | |
| 411. | 0820427 | [2] | BOLT;SOCKET | |
| 412. | 0820428 | [1] | BOLT;SOCKET | |
| 413. | M341025 | [5] | BOLT;SOCKET | |
| 414. | M340820 | [4] | BOLT;SOCKET | |
| 467. | 0629404 | [2] | PLUG | |
| 469. | 0697911 | [3] | PLUG | |
| 490. | 0263019 | [20] | PLUG | |
| 491. | 0451028 | [14] | PLUG | |
| 492. | 0451027 | [4] | SCREW | |
| 493. | 0102440 | [2] | PLUG | |
| 530. | 0820438 | [2] | PIN ASS'Y | |
| 530A. | +++++++ | [2] | PIN | |
| 530B. | +++++++ | [2] | PIN | |
| 532. | 0820429 | [2] | PISTON;SERVO | |
| 534. | 0451031 | [2] | STOPPER | |
| 535. | 0820430 | [2] | STOPPER | |
| 536. | 0820431 | [2] | COVER | |
| 540. | 0820444 | [2] | VALVE;CHECK ASS'Y | |
| 541. | 0820441 | [1] | SEAT | |
| 543. | 0820442 | [1] | STOPPER | |
| 545. | 0221509 | [1] | BALL;STEEL | |
| 702. | 0451033 | [2] | O-RING | |
| 709. | 0694604 | [1] | O-RING | |
| 711. | 0820432 | [1] | O-RING | |
| 712. | 0820433 | [1] | O-RING | |
| 724. | 0443801 | [7] | O-RING | |
| 725. | 4297379 | [6] | O-RING | |
| 726. | 0443405 | [2] | O-RING | |
| 728. | 0443408 | [3] | O-RING | |
| 732. | 0451035 | [2] | O-RING | |
| 752. | 0820439 | [2] | PACKING | |
| 774. | 0820443 | [1] | SEAL;OIL | |
| 789. | 0451036 | [2] | RING;BACK-UP | |
| 792. | 0451037 | [2] | RING;BACK-UP | |
| 804. | 4469592 | [2] | UNIT | |
| 806. | 0451038 | [2] | NUT | |
| 807. | 0820434 | [2] | NUT | |
| 823. | 959499 | [1] | RING;RETAINING | |
| 824. | 991345 | [3] | RING;RETAINING | |
| 825. | 488075 | [2] | RING;RETAINING | |
| 827. | 991728 | [1] | RING;RETAINING | |
| 828. | 0820435 | [2] | RING;RETAINING | |
| 885. | 0313404 | [2] | PIN | |
| 886. | 0244604 | [4] | PIN;SPRING | |
| 887. | 0175240 | [1] | PIN | |
| 888. | 0820436 | [2] | PIN | |
| 889. | 0820449 | [4] | PIN | |
| 901. | 0134458 | [2] | BOLT;EYE | |
| 953. | 0820450 | [2] | SCREW;SET | |
| 954. | 0682328 | [2] | SCREW;SET | |
| 974. | 0451203 | [4] | WASHER | |
| 981. | +++++++ | [1] | NAME-PLATE | |
| 983. | 0625509 | [2] | PIN | |
| 995. | 4444902 | [2] | SENSOR;ANGLE | |
| 996. | 4255077 | [2] | SPRING;PLATE | |
| 997. | 4274371 | [2] | O-RING |
