Parts scheme
List of spare parts
| Pos. | Part No | Qty | Parts name | Remark |
|---|---|---|---|---|
| . . | 24100N6332F3 | [1] | PUMP | KOB PUMP ASSY, CONNECT |
| 1. | 2437U390F1 | [1] | PUMP | KOB APPLICABLE: LE14101-15754, SEE (C.P.M) (13) Superseded by part number: 2437U486F1 |
| 2. | 2416N5695 | [1] | BRACKET | |
| 3. | 24100U341F1 | [1] | COUPLING | KOB Superseded by part number: LF30P01001F1 |
| 3-1. | 24100U341S1 | [1] | COUPLING | KOB Superseded by part number: LF30P01001S001 |
| 3-2. | 2418U128S5 | [6] | SCREW | KOB M16x2.0x50mm Long Superseded by part number: LQ30P01003S005 |
| 3-3. | ZP26D05010 | [9] | PIN | KOB Roll -- OD 05 x 10mm Long |
| 4. | 2418P23473 | [1] | HUB | KOB |
| 5. | ZS23C16040 | [4] | CAPSCREW,Hex Socket Head, M16 x 40mm | KOB SCREW M16x2.0x40mm |
| 6. | ZS13C10035 | [5] | SCREW | KOB M10x1.50x35mm Superseded by part number: ZS18C10035 |
| 9. | ZW22K16000 | [4] | LOCK WASHER | KOB ID 16 x OD 24 x Th 3.5mm |
| 10. | ZW22X10000 | [8] | LOCK WASHER | KOB ID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 12. | ZS13C10045 | [3] | SCREW | KOB M10x1.50x45mm Superseded by part number: ZS18C10045 |
| 13. | 2437U486F1 | [1] | PUMP | KOB ASSY, APPLICABLE: LE15755-, SEE (C.P.M) |
| Pos. | Part No | Qty | Parts name | Remark |
|---|---|---|---|---|
| . . | 2437U390F1 | [1] | PUMP | KOB Superseded by part number: 2437U486F1 |
| 1. | 2480U328F1 | [1] | CONTROL | KOB |
| 2. | 2416R481F1 | [1] | HANGER | KOB HAN |
| 3. | 24100R232F1 | [2] | ROTARY DIVIDER | KOB |
| 4. | 2414R430F1 | [1] | COVER ASSY | |
| 5. | 2410R335F1 | [1] | CASE | KOB |
| 5-1. | NSS | [1] | NOT SOLD SEPARAT | CON CASE |
| 5-2. | ZR26X06200 | [1] | SNAP RING | KOB |
| 5-3. | NSS | [1] | NOT SOLD SEPARAT | CON OIL SEAL |
| 5-4. | 2410R335S4 | [1] | O-RING | KOB |
| 6. | 2437U386F1 | [1] | PUMP | HIT |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CON SHAFT |
| 8. | 2437U390S8 | [1] | CONTACT PLATE | KOB PLATE, CONTROL |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CON BEARING |
| 10. | 2414R268S3 | [2] | PIN | |
| 11. | 2437U390S11 | [1] | SHIM | KOB SHIM |
| 12. | ZR16X02800 | [1] | SNAP RING | KOB |
| 13. | 2437U390S13 | [1] | PLUG | |
| 14. | ZD12P01100 | [1] | O-RING | KOB ID 10.8mm x OD 13.2mm |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CON NAME PLATE |
| 15-1. | NSS | [2] | NOT SOLD SEPARAT | CON SCREW |
Product description
| Appliion Hitachi | Kobelco Yucai Doosan Excavator |
| Quality | High Guarantee |
| Model | SK60-7 YC85 DH80 |
| Package | Standard Packing at Normal |
| Warranty | 1 Year |
| Payment term | T/T,, PayPal, Alibaba Trade Assurance |
| Delivery | 2 days after the payment received |
| Shipment | by sea, by air, by express or as required |
