| # | Part No | Part Name | Comment | Qty. |
| 1E | 2401-1276KT | SEAL KIT, FUEL TRANSFER PUMP | 1 | |
| 2 | 195-01628 | BRACKET, FUEL PUMP | 1 kg | 1 |
| 3 | 2120-2196D10 | BOLT, SET M12X1.75X25 | 9 | |
| 4 | S0508853 | BOLT, HEX | 4 | |
| 5 | S5102503 | WASHER, SPRING | 4 | |
| 6 | 2181-2104D6 | ADAPTER, S | 1 | |
| 7 | S8000181 | O-RING | 1BP18 | 1 |
| 8 | S8470032 | CLAMP, HOSE(AWAB) | 3 | |
| 9 | 2185-1247D148 | HOSE | 1 kg | 1 |
| 11 | 185-00167D3 | HOSE ASS`Y | 2 kg | 1 |
| 11A | 2420-1258 | VALVE, CHECK | 1 | |
| 11B | 2471-1152 | STRAINER | 1 | |
| 11C | 2160-1336 | CAP, STRAINER | 1 | |
| 12 | 195-01630 | BRACKET | 2 | |
| 13 | 2549-9096 | SWITCH, TOGGLE | 1 | |
| 14 | 2114-1683 | WASHER, TOGGLE SWITCH | 1 | |
| 15 | 190-00519 | PLATE, NAME(FUEL PUMP) | 1 | |
| 16 | 124-00208D5 | CLIP | 4 | |
| 18 | S5010513 | WASHER, PLAIN | 4 | |
| 19 | 530-00214 | HARNESS, TOGGLE SWITCH | 1 | |
| 20 | 120-00276 | BOLT M8X1.25X12 | 2 | |
| 21 | 195-02179 | BRACKET | 1 | |
| 22 | 195-02180A | BRACKET | 1 | |
| - | 401-00339 | FUEL FILLER PUMP ASS'Y | ||
| 1 | 401-00238 | PUMP , FUEL TRANSFER | 4 kg | 1 |
| 1A | 2181-2755B | ADAPTER | 2 | |
| 1B | S8180321 | RING, SEAL | 2 | |
| 1C | 523-00012 | MOTOR, FUEL TRANS. PUMP | 2 kg | 1 |
| 1D | 407-00001 | ROTOR & VANE | 1 |
