List of spare parts
# | Part No | Part Name | Qty. | Price request |
---|---|---|---|---|
8277784 | ||||
SA 1143-01270 | Travel motor SER NO 10001-12714SER NO 30001-30315 |
1 | ||
VOE 14524184 | Travel motor SER NO 12715-14677SER NO 30316-30780 |
1 | ||
VOE 14533651 | Travel motor SER NO 14678-SER NO 30781- |
1 | ||
1 | SA 8230-21631 | Piston | 1 | |
2 | SA 8230-28900 | Piston | 9 | |
3 | VOE 14500075 | Piston | 1 | |
4 | VOE 14500076 | Seat | 1 | |
5 | Block | 1 | ||
6 | SA 8230-21530 | Plate | 1 | |
7 | SA 8230-21540 | Ball | 1 | |
8 | SA 8230-31160 | Washer | 2 | |
9 | SA 8230-21560 | Washer | 1 | |
10 | SA 8230-21570 | Spring | 1 | |
11 | VOE 14500077 | Ring | 1 | |
12 | VOE 14500078 | Bearing | 5 | |
13 | SA 8230-15140 | Piston | 1 | |
14 | VOE 14500079 | Piston | 1 | |
15 | VOE 14500080 | Seat | 1 | |
16 | SA 8230-33140 | Shaft | 1 | |
17 | SA 8230-21520 | Plate | 1 | |
18 | SA 8230-21550 | Plate | 1 | |
19 | SA 8230-21650 | Piston | 1 | |
20 | SA 8230-21660 | Spring | 12 | |
21 | SA 8230-21670 | Plate | 2 | |
22 | SA 8230-03560 | Plate | 2 | |
23 | SA 8230-27160 | Sealing ring | 1 | |
24 | SA 9511-12175 | O-ring | 1 | |
25 | SA 9511-12210 | O-ring | 1 | |
26 | SA 8230-21580 | Ball Bearing | 1 | |
27 | SA 8230-21590 | Ball Bearing | 1 | |
28 | SA 8230-21600 | Support | 2 | |
29 | SA 8230-21610 | Pin | 4 | |
30 | SA 8230-15150 | Spring | 1 | |
31 | VOE 14500089 | Spindle SER NO 10001-14677SER NO 30001-30780 more |
1 | |
VOE 14535473 | Spindle SER NO 14678-SER NO 30781- more |
1 | ||
32 | SA 9511-12008 | O-ring more | 2 | |
33 | SA 9511-22230 | O-ring | 1 | |
34 | SA 8220-13340 | Pin | 1 | |
35 | VOE 14500083 | Flange | 1 | |
36 | SA 8230-21790 | Flange | 1 | |
37 | VOE 14500084 | Flange | 1 | |
38 | VOE 14500085 | Spool | 1 | |
39 | VOE 14535476 | Piston | 1 | |
40 | SA 8230-02710 | Plug | 2 | |
41 | SA 8230-21700 | Stop | 2 | |
42 | SA 8230-03590 | Plug | 2 | |
43 | SA 8230-03600 | Check valve | 2 | |
44 | SA 8230-02760 | Spring | 2 | |
45 | SA 8230-03610 | Spring | 2 | |
46 | SA 8220-14930 | Plug | 4 | |
47 | SA 9511-12032 | O-ring more | 2 | |
48 | SA 9511-1222A | O-ring | 2 | |
49 | SA 8230-30410 | Plug | 2 | |
50 | SA 8230-19210 | Plug | 2 | |
51 | SA 8220-14920 | Plug | 8 | |
52 | SA 8230-20520 | Plug | 2 | |
53 | SA 8230-21710 | Spool | 1 | |
54 | VOE 14500087 | Spring | 1 | |
55 | SA 9676-38000 | Ball SER NO 10001-14677SER NO 30001-30780 more |
2 | |
VOE 14535475 | Ball SER NO 14678-SER NO 30781- more |
2 | ||
56 | SA 8230-08630 | Filter | 1 | |
57 | SA 8230-23140 | Plug | 2 | |
58 | SA 8230-21890 | Plug | 2 | |
59 | SA 9511-12005 | O-ring | 2 | |
60 | SA 9511-12008 | O-ring more | 2 | |
61 | VOE 14500088 | Ball | 2 | |
62 | SA 9511-12011 | O-ring more | 2 | |
63 | SA 9511-12018 | O-ring more | 2 | |
64 | SA 9511-12014 | O-ring more | 2 | |
65 | SA 8230-27130 | Orifice SER NO 10001-14677SER NO 30001-30780 more |
1 | |
VOE 14535474 | Orifice SER NO 14678-SER NO 30781- more |
1 | ||
66 | SA 9016-11608 | Bolt | 12 | |
67 | SA 8230-21640 | Relief valve | 2 | |
100 | SA 8230-21810 | Sealing Kit more | 1 |
|
Product description
Appliion | Excavator |
Quality | High Guarantee |
Model | EC210BLC |
Package | Standard Packing at Normal |
Warranty | 1 Year |
Payment term | T/T,, PayPal, Alibaba Trade Assurance |
Delivery | 2 days after the payment received |
Shipment | by sea, by air, by express or as required |
1 . If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the size for reference.
2 . What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.The genuine parts we don't have the warranty of it,but just can make sure it is 100% genuine.
3 . How can I pay the order?
You can finish the payment by T/T,Western Union,Paypal etc.
4 . When will get the items after I place order?
Once we received your payment , we will arrange the shipment within 24 hours ; if don't have stock , we will tell you before payment .
5 . How can I do if there is something wrong with the items?
First of all , I have confidence in the quality of our products ,if you really found something wrong ,please provide pictures for us and we will check. After it is confirmed, please return to us , we will offer the correct item.
6 . What is your main products ?
Our pain product is final drive , hydraulic pump , swing gearbox , travel gearbox , swing motor , hydraulic parts . If you need any parts for crawler excavator , you can ask us too . We will try our best to meet your requirement.
